Materials Specifications
Doors, sides, partitions, top, backs, internal shelves: made of particle wood panels - class E1 for low formaldehyde emission.
Note: melamines with wood effect, Metal Smoke textured and Gurè textured always come with vertical veins.
Technical Specifications and Equipment
Sides and Partitions: thickness cm 2,2. Equipped with levelling feet inserted in the structure (cm 0,5 empty, to be added to the overall height of the wardrobe) and adjustable cm 1 from the inside.
Top:cm 2,2 thick equipped with fixing joints.
Bottom: thick equipped with fixing joints.
Backrest: thickness cm 0,8.
Internal shelf: cm 3,5 thick equipped with fixing joints.
Door: cm 2,2 thick equipped with soft closing mechanism. It features a handle or a full-height recess grip: white or titanium painted metal or in several matt lacquered metal finish.
Drawer: cm 2,2 thick, cm 15,7 high equipped with soft closing mechanism and full extension runners. It features an horizontal handle or recess grip (the first drawer next to the shelf does not have a recess grip but a handle built-in the lower side): white or titanium painted metal or in several matt lacquered metal finishes.
Basket: thickness cm 2,2 height cm 31,7 equipped with soft closing system. It features an horizontal handle or recess grip: white, titanium painted metal or in several matt lacquered metal finishes.
Handle:
- push-pull
- Ellie: cm 14,8 d.2,2 h.2,5. White or titanium painted, matt lacquer.
- Katy: cm 12,3 d.2,2 h.3. White or titanium painted, matt lacquer.
- Z: cm 31,3 d.1,8 h. 0,9. Brushed steel finish, white or titanium painted, matt lacquer.
- Hobby: cm Ø 2,2 d.2,2. White or titanium painted, matt lacquer.
- Ponte: cm 32,6 d.2,7 h.1,2. Brushed steel, white or titanium painted, matt lacquer.
Assembling Tips
In order to assemble the structure you need:
- in width cm 4
- in height cm 2,5 (cm 0,5 for the adjustable feet + cm 2 for the assembling). In case you select the optional lighting system the cm becomes 3,5.
